2-126.04 Dual-Key Cylinder Swinghandle RS 130 PA



  • Dual-key cylinder swinghandle with pivotable operating lever
  • Fully insulated for installation in plastic cabinets
  • Can be opened with either of the two key cylinders. Accepts 40mm and 45mm profile cylinders
  • Latch bolt securely locked against unauthorized opening
  • IP65 according to DIN EN 60529
  • a) Latch bolt with chamfer. Closing is possible if key is removed
  • b) Latch bolt with detent. Detent requires turning the key


  • Swinghandle and dish: PA, black


(S) Door-thickness 3mm - max. 6mm

To use the same door both RH and LH, 2 holes □46, symmetrical to door center are possible.

Upgrading with steel insert (saw protection) possible

Dual-Key Cylinder Swinghandle RS 130 PA.

More Information
Material Polyamide (PA)
