GN 949-D Stainless Steel-Handwheels with revolving handle

Manufacturer:
GANTER

Types

  • Type A: without handle
  • Type D: with revolving handle

Bore codes

  • Version B: without keyway
  • Version K: with keyway

Stainless Steel precision casting

  • AISI CF-8
  • Hub machined
  • Rim turned
  • Matt shot-blasted

Revolving handles

  • Plastic Duroplast, black, shiny finish
  • Spindle Stainless Steel AISI 304
Stainless Steel-Handwheels with revolving handle.
SKU d1 d2 H8 d3 b l1 l2 ≈ l3 ≈ r Ø Handle No. of spokes Shipped In Price *
GN 949-100-B10-D 100 10 20 7 15 27.5 45 44 18 3 5-7 Days €39.45
GN 949-100-B12-D 100 12 20 7 15 27.5 45 44 18 3 5-7 Days €39.45
GN 949-100-K10-D 100 10 20 7 15 27.5 45 44 18 3 5-7 Days €42.43
GN 949-100-K12-D 100 12 20 7 15 27.5 45 44 18 3 5-7 Days €42.43
GN 949-125-B12-D 125 12 24 9 16 28.5 55 55 21 3 5-7 Days €56.64
GN 949-125-B14-D 125 14 24 9 16 28.5 55 55 21 3 5-7 Days €56.64
GN 949-125-K12-D 125 12 24 9 16 28.5 55 55 21 3 5-7 Days €59.63
GN 949-125-K14-D 125 14 24 9 16 28.5 55 55 21 3 5-7 Days €59.63
GN 949-140-B14-D 140 14 28 10 18 30.5 70.5 62 23 3 5-7 Days €69.76
GN 949-140-B16-D 140 16 28 10 18 30.5 70.5 62 23 3 5-7 Days €69.76
GN 949-140-K14-D 140 14 28 10 18 30.5 70.5 62 23 3 5-7 Days €72.74
GN 949-140-K16-D 140 16 28 10 18 30.5 70.5 62 23 3 5-7 Days €72.74
GN 949-160-B14-D 160 14 31 11 20 35.5 70.5 71 23 3 5-7 Days €87.29
GN 949-160-B16-D 160 16 31 11 20 35.5 70.5 71 23 3 5-7 Days €87.29
GN 949-160-K14-D 160 14 31 11 20 35.5 70.5 71 23 3 5-7 Days €90.27
GN 949-160-K16-D 160 16 31 11 20 35.5 70.5 71 23 3 5-7 Days €90.27
GN 949-200-B18-D 200 18 36 14 23 39 70.5 90 23 3 5-7 Days €118.58
GN 949-200-B20-D 200 20 36 14 23 39 70.5 90 23 3 5-7 Days €118.58
GN 949-200-K18-D 200 18 36 14 23 39 70.5 90 23 3 5-7 Days €121.56
GN 949-200-K20-D 200 20 36 14 23 39 70.5 90 23 3 5-7 Days €121.56
* Special pricing for OEM´s and resellers available. Quantity-based discounts available as well.
More Information
Material Stainless steel
High performing lines Inox
Type of assembly Plain hole, Plain hole and keyway
Handle Revolving handle
